RSCO Single-acting Hollow Plunger Cylinders HCB5-100T

Brand:
رستگار صنعت - RASTEGAR SANAT

Hydraulic Jack

Information:

  • Power: 100 tons / 946 KN
  • stroke 75mm
  • Effective area: 135.2 cm
  • Oil capacity: 1015 cm3
  • Closed mode height: 276 mm
  • extended height 351 mm
  • outside diameter 212 mm
  • inside diameter 165 mm
  • center hole(G) : 80 mm
  • piston rod diameter 127 mm
  • Weight: 57 kg
  • Made in China
  • Hollow plunger design allows for both push and pull forces
  • Single acting, spring return
  • High strength alloy steel for durability
  • Baked enamel finish for increased corrosion resistance
  • Each cylinder has an HH-II R2 3/8 male half coupler and dust cap
  • Contact us for more information
Read moreShow less
Add to compare0
authenticity and physical health of the product warranty
Available in stock
هفت روز مهلت تست کالا هفت روز مهلت تست کالا
Cash On Delivery tehran Cash On Delivery tehran
Specialized advice when shopping Specialized advice when shopping
$284.40
Delivery: 1 to 3 weeks
Product Details

Data sheet

Name
Hydraulic Jack
Device Model
HC-60
Function system
Hydraulic
Maximum pressure
700 bars
Warranty
Unavailable
Made in
china
Weight
57 kg
Overall length
351 mm
Tank capacity
1015 ml
نوع جک
Single-acting Hollow Plunger Cylinders
ظرفیت جک
100T
