INSIZE Feeler Gauge 4602-17

Dial Thickness gauge

Information:

• The thickness gauge is used to measure the thickness of dimensions with high accuracy.
• Measurable size: 0-10 mm
• Clockwise operating system
• Ceramic jaws
• Measuring depth: 20 mm
• Plate diameter: 58 mm
• Accuracy: ±0.02 mm
• High build quality
• Grading in terms of 0.01 mm
• It has a hand screen for display
• Made in China

SMART Brass Feeler Gauge

Information:

• We use Filler gauge measure to measure and control dimensions.
• It has 20 brass measuring blades.
• Material : Brass
• Working system : manual
• Size on each blade in mm.
• Ability To Use in petrochemicals and gas-filled environments
• Made with high quality.
• The size of the blades: From 0.05 to 1 mm
• conical blades
• Made in Germany
• Contact us for more information.

BLATT Feeler Gauge

Information:

• We use Filler gauge measure to measure and control dimensions.
• It has 20 measuring blades.
• Made of stainless steel.
• Working system : manual
• Size on each blade in metric.
• Made with high quality.
• The size of the blades: From 0.05 to 1 mm
• Blade length : 100mm

• Conical blades.
• Made in Germany
• Contact us for more information.

PROTO Feeler Gauge

Information:

• We use Filler gauge measure to measure and control dimensions.
• It has 25 measuring blades.
• Made of stainless steel.
• Working system : manual
• Size on each blade in millimeter and inch.
• Made with high quality.
• The size of the blades: From 0.0015 to 0.040 inch
• Weight : 86g
• Made in America
• Contact us for more information.

Industrial ruler

Information:

• Use a ruler to draw lines or use the scale included in the ruler to measure.
• This type of counter is used to display the output and data of this ruler.
• Digital operation system
• Equipped with a digital screen
• Measurable size: 1000 mm
• Accuracy: ±5 microns
• Made of stainless steel
• Moving speed: 50 meters per minute
• Resolution: 1 micron
• Cable length: 5 meters
• Comes with mounting base, dust cover, L-shaped bracket and accessories for installation
• Made in China

Industrial square

Information:

• A compound gonior is a measuring and protractor tool commonly used for staking out 90° angles, staking out 45° angles, finding the center of a circle, finding the depth of a slot or hole, and measuring simple and short distances.
• Can be used to obtain the slope of the surface
• Used for measuring and entering angles as well as controlling angles
• It has protractor, ruler, ruler and center finder
• 0.5 mm and 1/32 inch graduations on the ruler
• 1 mm and 1/64 inch graduations on the back of the ruler
• Ability to measure and control in two angles of 45 and 90 degrees
• Accuracy at 90 degree angle: ±8 seconds
• Accuracy at 45 degree angle: ±10 seconds
• Protractor size: 0-180 degrees
• Ruler length: 300 mm
• Center finder with accuracy: ±0.15 mm
• Using the center finder to find the center of the cylinder or rotating objects
• High build quality
• Made in China

Industrial square

Information:

• Industrial ruler is used for measuring and inserting angles as well as controlling angles.
• The overall length of the ruler: 0-300 mm
• Width: 120 mm
• Thickness: 18 cm
• Has an indicator needle
• Ruler made of stainless steel against rust
• Ability to align in two angles of 45 and 90 degrees
• Gunya height: 3 inches
• Has a number of water bubbles for leveling
• Chrome plated ruler blade for long life
• Graduation in centimeters and inches
• Made in England

Thickness gauge

Information:

• The thickness gauge is used to measure the thickness of dimensions with high accuracy.
• Measuring range: 0-10 mm
• Accuracy: ±0.1 mm
• Gradation in terms of 0.05 mm
• Scratch and wear resistant glass
• Total length: 85 mm
• Length of jaws: 35 mm
• Plate diameter: 50 mm
• More accuracy due to existing grooves
• It has a hand screen for display
• Made in China
